R1035 multi-function electric wheelchair

Product Center > Mobility Scooter R- series > 4.2 Electric Wheelchair > R1035 multi-function electric wheelchair

Item Description
Dimension(not include headrest height) 125*65*110cm
Seat width-depth-height 45cm-45cm-55cm
Wheels Front 9' air tire
Rear 14' air tire
Weight Capacity 120KGS
Controller 70A
Motor 24V DC 320W
Battery Capacity 24V 55Ah
weight 17kg*2
Dimension 23*138*22.6cm*2
Charger 24V x 5AMP
Recharge time 8-10hrs
Incline capability 8-15 degrees
Max speed 8-10KM/H
Range 40±5km
Suspension Front without
Rear with
Net weight（without batteries） 145kg
Gross weight 180kg
Package number 1ctn
size 112*72*95 cm
